SOLO MOTORSPORTS STAGE 1 MID-TRAVEL FRONT SUSPENSION KIT

SOLO MOTORSPORTS STAGE 1 MID-TRAVEL FRONT SUSPENSION KIT

Regular price $2,549.00 USD
Regular price Sale price $2,549.00 USD
Sale Sold out
SOLO MOTORSPORTS STAGE 1 MID-TRAVEL FRONT SUSPENSION KIT

The Stage 1 Kit is a high performance mid-travel front suspension upgrade for your Bronco and F-150. It provides 4 inches of lift and a healthy 12 inches of usable suspension travel. This will dramatically improve handling on the street and dirt.



The Dana 44 TTB Beams are “Cut N’ Turned” to allow for proper camber alignment with the 4-inch coils. The 1.25-inch Extended Radius Arms are equipped with heim joints and bring the vehicle’s camber to the correct value. Includes a set of Bilstein 5100 shocks, specifically valved and configured for a Bronco or F-150. A secondary shock option is also available that includes 4 Bilstein 5100 shocks at 2 per side. A set of heavy-duty extended stainless brake lines for the front and rear is also included.



SPECS:

12 inches of front suspension travel
4 inches of front suspension lift
Clears 35-inch tire
No fiberglass fenders required
No driveshaft modification required



INCLUDES:

Dana 44 Cut N’ Turned TTB Beam Work (core charges apply – read more)
4-inch Coils (2x)
1.25-inch Heimed Extended Radius Arms with Pivot Brackets, Misalignment Spacers and Grade 8 Hardware
3-Piece Extended Brake Line Kit for the front and rear
Front Alignment Cams (2x)
Drop Pitman Arm (1x)
Option of Bilstein 5100 Shock Set (2 behind the coils) or Bilstein 5100 Shocks (2 in front and 2 behind the coils)
Includes all necessary mounting tabs and hardware. Welded upon request at no charge.



APPLICATIONS: 80-97 Bronco, 4WD F-150
